$22,000.00 + GST ($24,200.00 Inc. GST)
- Closed
Details
| Quantity | : | 1 Unit |
| Unit Price | : | $22,000.00 + GST ($24,200.00 Inc. GST) |
| Status | : | For Sale |
| Location | : | Elmore, Northern Country, VIC |
| Category | : | Machinery & Equipment, Weighbridge or Weighing |
| Listing Date | : | 28/07/2016, 07:57pm |
Description
AXLE PAD SCALES FOR SALE, The Alternative to the weighbridge / weighbridge for farmers!
They are Canadian made Pad Scales and commonly used there in many different areas.
They are a cheaper option for private setups without having to purchase on a commercial scale for a lower usage setup / requirement.
There are many options and below is the main one that has been focused on so far,
14ft , with 4 ramps , 8 load cells , quick connect Indicator and Display box plus printer and power cords.
The Base needs to be as best setup as possible as it is the foundation for the whole exercise, so Level Concrete is the best way to go.
Specification
Rated Capacity (pounds) 84" axle scale: 30K per pad (60K per axle grouping)
144" axle scale: 40K per pad (80K per axle grouping)
168" axle scale: 30K per pad (80K per axle grouping)
Load Cells ML 1100-25K (Output: 2mV/V)
Accuracy Wheel loads accurate to 0.25% FS nominal
Overload Capacity 150% full scale safe overload
300% full scale ultimate overload
Temperature Range -40ºC to +80ºC (operating)
-10ºC to +40ºC (compensated)
Graduation 20lb (30K and 40K capacity)
Material Heavy duty high strength steel
Fatigue Limit Infinate cycles per day (wheel loads)
Ground Requirements The ground must be flat and level, with proper drainage
Dimensions 84" x 30" x 6" (weighing surface)
144" x 30" x 6" (weighing surface)
168" x 30" x 6" (weighing surface)
Sealing Standard IP-66: totally protected from dust; protected from strong jets of water
Power Axle scales are powered by a wired load cell display
Please Inquire for more info and pricing,
They are Canadian made Pad Scales and commonly used there in many different areas.
They are a cheaper option for private setups without having to purchase on a commercial scale for a lower usage setup / requirement.
There are many options and below is the main one that has been focused on so far,
14ft , with 4 ramps , 8 load cells , quick connect Indicator and Display box plus printer and power cords.
The Base needs to be as best setup as possible as it is the foundation for the whole exercise, so Level Concrete is the best way to go.
Specification
Rated Capacity (pounds) 84" axle scale: 30K per pad (60K per axle grouping)
144" axle scale: 40K per pad (80K per axle grouping)
168" axle scale: 30K per pad (80K per axle grouping)
Load Cells ML 1100-25K (Output: 2mV/V)
Accuracy Wheel loads accurate to 0.25% FS nominal
Overload Capacity 150% full scale safe overload
300% full scale ultimate overload
Temperature Range -40ºC to +80ºC (operating)
-10ºC to +40ºC (compensated)
Graduation 20lb (30K and 40K capacity)
Material Heavy duty high strength steel
Fatigue Limit Infinate cycles per day (wheel loads)
Ground Requirements The ground must be flat and level, with proper drainage
Dimensions 84" x 30" x 6" (weighing surface)
144" x 30" x 6" (weighing surface)
168" x 30" x 6" (weighing surface)
Sealing Standard IP-66: totally protected from dust; protected from strong jets of water
Power Axle scales are powered by a wired load cell display
Please Inquire for more info and pricing,
