Kusing 25KVA Silenced Diesel Generator 3 Phase 415V
$8,363.64 + GST ($9,200.00 Inc. GST)
Details
| Quantity | : | 4 Units |
| Unit Price | : | $8,363.64 + GST ($9,200.00 Inc. GST) |
| Status | : | For Sale |
| Location | : | DARRA, Southeast Coast, QLD |
| Category | : | Machinery & Equipment, Generators |
| Listing Date | : | 18/08/2023, 01:50pm |
Description
Main Features
• 4 pole brushless alternator with zero THD delivering clean stable energy.
• Safe to use on digital electronic equipment.
• Water-cooled diesel engine for round the clock use in extreme conditions.
• User friendly controller with instruction manuals available.
• Some generators are ATS/Auto start connection equipped (check spec sheet).
• Compliant with Australian safety standards.
• Strong weatherproof silent canopy with various lifting locations
Recommendations
• To maintain a healthy engine, it is recommended to run a minimum load of 40% to prevent cylinder glazing or wet stacking.
• Even loading across all 3 phases will ensure a long life of your alternator.
• This generator is weatherproof however, it is recommended to station the generator under cover if possible.
• Change all fluids after 50 hours and continue with the scheduled service plan as per instruction book.
• If using the generator in a remote location, a distribution board can offer different sized power outlet options (see your electrician for advice).
Safety Features
• Emergency stop
• Battery Isolator
• Over temperature protection
• Low oil protection
• Low fuel alarm
• RCD protection
• Over current protection
• Battery DC charge fault alarm
• Phase imbalance protection
• Full canopy soundproofing with lockable doors
• Poly baffled fuel tank
• Fire extinguisher (by request)
Specifications:
Generator Model K302000
Prime Power 25KVA
Standby Power 27.5KVA
Rated Current 36 Amps per phase
Canopy Silenced
ATS (Auto Transfer Switch) 2 wire start connection installed for ATS (ATS add $500)
Fuel Tank Capacity Est. 120 Litres
Noise Level 75dB @ 7m
Controller Kusing AD6122
Main Breaker Switch 63A
Power Outlets N/A
Internal Protection IP22
Dimensions 2250L x 960W x 1250H mm
Weight 950kg
Engine Make Yang Dong
Engine Model YSD490D
Bore 90mm
Stroke 100mm
Air Aspiration Natural
RPM 1500
Speed Governor Mechanical
Start System 12V
Fuel Consumption 4.9 L/hr at 100% load
Oil Specification 15W/40
Oil Sump Capacity 6 Litres
Coolant Capacity 9 Litres
Alternator Make Kusing
Alternator Model S184G20D8
Voltage 415V
Phase 3 phase
Frequency 50Hz @ 1500 RPM
Power Factor 0.8 (lagging)
Voltage Tolerance +/- 1%
Insulation Class H
Warranty
All of our industrial diesel generators come with a standard 12 month/1000 hour warranty.
Shipping
For a shipping price to deliver to your location, please contact us.
We deliver anywhere in Australia with a few exceptions, also servicing PNG and the South Pacific regions.
For all deliveries, we recommend delivery to your nearest major centre for depot collection.
